| Physical Characteristics | |
| Dimensions | 177.0 x 80.2 x 14.8mm / 6.97 x 3.15 x 0.58in |
| Weight | 626g / 22.08oz. (device with battery) |
| Display | 5-inch (Fingerprint); 1280 x 720 / 6-inch; 2160 x 1080 |
| Touch Panel | Multi-touch panel, gloves and wet hands supported; Corning Gorilla Glass |
| Power | 6700mAh / 13400mAh removable pistol battery Built in 100mAh backup battery, supporting battery hot swap |
| Notification | Sound, LED indicator, vibrator |
| Interfaces | USB 2.0 Type-C, OTG, Type-C headphones supported |
| Card slot | 2 slots for PSAM card (optional); 1 slot for Nano SIM card, 1 slot for Nano SIM or TF card |
| Audio | 1 microphone; 1 speaker; 1 receiver |
| Keypad | 1 power key, 2 scan keys, 1 user-defined key, 2 volume keys (+/-) |
| Sensors | Gravity sensor, proximity sensor, light sensor, geomagnetic sensor (optional), gyroscope (optional) |
| Communication | |
| WLAN | 802.11 a / b / g / n / ac, 2.4G / 5G dual-band |
| WWAN | 2G: GSM (B2 / B3 / B5 / B8) 3G: WCDMA (B1 / B2 / B4 / B5 / B8) CDMA2000 ECDO: BC0 4G: B1 / B2 / B3 / B4 / B5 / B7 / B8 / B12 / B17 / B20 / B28A / B28B / B38 / B39 / B40 / B41 |
| Bluetooth | 5.0 |
| Vo-LTE | Support |
| GNSS | GPS / AGPS, GLONASS, BeiDou, Galileo |
| Developing Environment | |
| Operating System | Android 11/13 |
| SDK | Chainway Software Development Kit |
| Language | Java |
| Tool | Eclipse / Android Studio |
| Performance | |
| CPU | Octa-core, 2.3GHz |
| RAM+ROM | 3GB + 32GB 4GB + 64GB (Optional) |
| Expansion | Supports up to 256GB Micro SD (TF) card |
| User Environment | |
| Operating Temp. | -20 °C to 50 °C / 4 °F to 122 °F |
| Storage Temp. | -40 °C to 70 °C / -40 °F to 158 °F |
| Humidity | 5% RH - 95% RH (non condensing) |
| Drop Specification | Multiple 1.5m / 4.9ft. drops to the concrete across the operating temperature range |
| Tumble Specification | 1000 x 0.5m / 1.64 ft. falls at room temperature |
| Sealing | IP65 per IEC sealing specifications |
| ESD | ±15KV air discharge, ±8KV conductive discharge |
| Barcode Scanning | |
| 2D Imager Scanner | CM60; Zebra: SE4710 |
| 1D Symbologies | UPC / EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS etc. |
| 2D Symbologies | PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX) etc. |
| Note | *This function is optional |
| UHF RFID | |
| Engine | CM710-1 module based on Impinj E710 |
| Frequency | 865-868MHz / 920-925MHz / 902-928MHz |
| Impinj Gen2X | Supported |
| Protocol | EPCglobal Gen 2 (ISO18000-6C) |
| Antenna | Circular polarization; 5dBic |
| Output Power | 1W (30dBm, +5dBm to +30dBm adjustable) 2W Optional (33dBm, for Latin America, etc.) |
| Fastest Read Rate | 1300+ tags / sec (Circular Polarized) |
| Max Read Range | 5dBi 30m (Impinj MR6 tag, size 70 x 15mm) 32m (Impinj M750 tag, size 70 x 15mm) 33m (Alien H3 Anti-Metal tag, size 130 x 42mm) 4dBi 22m (Impinj MR6 tag, size 70 x 15mm) 26m (Impinj M750 tag, size 70 x 15mm) 27m (Alien H3 Anti-Metal tag, size 130 x 42mm) |
| Note | * Ranges and rates depend on tags and environment |
| Fingerprint Recognition | |
| Fingerprint | TLK1NC02 |
| Note | * This function is optional |
| Camera | |
| Front Camera | 5MP |
| Rear Camera | Rear 13MP Autofocus with flash |
| NFC | |
| Frequency | 13.56MHz |
| Protocol | ISO14443A / B, ISO15693, NFC-IP1, NFC-IP2, Impinj Prtoected Mode Supported etc. |
| Chips | M1 card (S50, S70), CPU card, NFC tags etc. |
| Range | 2-4cm |
| Note | * This function is optional |
